2U Edge AI System for AI Agents and Private LLMs | Avalue

Processor

Intel® Core™ Ultra 5 / 7 / 9 processors (Arrow Lake-S), up to 65W

Chipset

Intel® Q870 Chipset

System Memory

4 x 288-pin CU-DIMM DDR5 6400 MHz, U-DIMM DDR5 5600 MHz, up to 256GB (64GB per DIMM)

Buttons

System Power, reset button

LED

Storage Activity

USB

7 x USB 3.2 Gen2 x 1 (Type-A)
1 x USB4 (Type-C)

Ethernet

1 x 1Gbps
1 x 2.5Gbps

Display

1 x HDMI 2.1
1 x DP 1.4a++

COM

COM1 (RS-232/422/485)

Audio

1 x Mic-in, 1 x Line-out, 1 x Line-in (Realtek ALC897 HD)

PCIe

2x PCIe x16 slots (1x Gen5 x16 signal or 2x Gen5 x8 signals) via Riser Cable

M.2

1x M.2 E-Key 2230 (PCIe Gen 4 x1)

Option

1x 10G LAN
2x COM
1x OOB

Consumption

Full loading : up to 2000Watts

Input / Connector

AC-in 110~220VAC
1,000W: 100~127V, 12A
2,000W: 220~240V, 10A

Net Weight

9.8 kg

Gross Weight

13.5 kg

Vibration

1Grms, IEC60068-2-64, Random, 5 ~ 500 Hz , 1Hr / Axis (operation, w/2x RTX Pro 6000 Blackwell)

Shock

10G, IEC 60068-2-27, Half Sine, 11 ms Duration (operation, w/2x RTX Pro 6000 Blackwell)

Temperature

Operating Temp.: 0°C ~ +40°C (32°F ~ 122°F)
Storage Temp.: -40°C ~ +85°C (- 40°F ~ 185°F)
*0°C ~ 35°C for RTX Pro 6000 Blackwell Workstation configurations

Humidity

Operating Relative Humidity: 8% to 80% (non-condensing)
Non-operating Relative Humidity: 8% to 90% (non-condensing)

OS Support

Windows 11/ Ubuntu 22.04

Security

TPM 2.0

Certification

CE / FCC Class A / UKCA / LVD / RoHS

W x D x H

438 x 500 x 88 mm

AIP-RQ87-A1QC

AIP-RQ87-A1QC Bare system w/2,000W CRPS power supply and Slide Rail (w/o CPU, RAM, SSD, GPU card)

AIP-RQ87-A1NV

AIP-RQ87-A1NV Bare system w/2,000W CRPS power supply and Slide Rail (w/o CPU, RAM, SSD, GPU card)

QUALCOMM CLOUD AI100 ULTRA

QUALCOMM AI 100 ULTRA, PCIE4.0 16X, 128G LPDDR4X, PASSIVE 150W, PCIE FH3/4L.

NVIDIA RTX PRO 6000 BLACKWELL WORKSTATION EDITION 96GB

PCIE Gen5.0 x16, NVIDIA RTX PRO6000, 96GB GDDR7, 4x DP2.1b, Dual slot, full height, Active thermal, 600W, 0°C to +40°C

NVIDIA RTX PRO 6000 BLACKWELL MAX-Q WORKSTATION EDITION 96GB

PCIE Gen5.0 x16, NVIDIA RTX PRO6000, 96GB GDDR7, 4x DP2.1b, Dual slot, full height, Active thermal, 300W, 0°C to +40°C
