Specification
Download
System Information
Processor
Intel® Pentium® Processor N4200 4C 1.1 GHz
Intel® Celeron® Processor N3350 2C 1.1 GHz
Intel® Celeron® Processor J3455 4C 1.5 GHz
System Memory
Onboard DDR3L 4GB Up to 8GB
I/O Chipset
EC iTE IT8528
BIOS
AMI uEFI BIOS, 128 Mbit SPI Flash ROM
Watchdog Timer
H/W Reset, 1Sec. ~ 65535Sec. and 1Sec./Step
H/W Status Monitor
Monitoring System Temperature, Voltage with Auto Throttling Control When CPU Temperature Monitoring V-Core Voltages Monitoring 5V Voltage Monitoring
Expansion
Expansion
3 x PCIe x1
Storage
Storage
Onbaord eMMC 5.0 Up to 64GB (Optional)
Display
Graphic Chipset
Intel® SoC Integrated Graphics
Spec. & Resolution
HDMI: Max. Resolution 3840x2160@30Hz or DP: Max. Resolution 4096x2160@60Hz
LVDS: Max. Resolution 1920x1200@60Hz or eDP: Max. Resolution 4096x2160@60Hz
Multiple Display
LVDS or eDP (Optional), HDMI or Display Port
LVDS
CH7511B(eDP to LVDS)
Audio
Audio Interface
Intel® HD Audio Integrated on CPU
Ethernet
LAN Chipset
1 x Intel® I210AT
Ethernet Interface
10/100/1000 Base-Tx Gigabit Ethernet Compatible
Software Support
OS
Windows 10
Linux
Android
Certification
Certification Information
CE, FCC Class, RoHS Compliant
I/O
USB
2 x USB 3.0
6 x USB 2.0
COM Port
1 x UART
PCIe
3 x PCIe x1
SATA
2 x SATA III
MIO
1 x SMBus
1 x LPC
1 x I2C
1 x SPI
Mechanical & Environmental
Operating Temp.
Standard 0°C ~ 70°C (32°F ~ 158°F)
Extended -20°C ~ 70°C (-4°F ~ 158°F)
Storage Temp.
-40°C ~ 85°C (-40°F ~ 185°F)
Operating Humidity
40°C @ 95% Relative Humidity, Non-condensing
Weight
0.095lbs (0.043Kg)
Power Requirement
+5V
Power Mode
AT
Dimension (L x W)
2.75" x 2.75" (70mm x 70mm)
Ordering Information
Ordering Information
EQM-APL-N4200-B2R
Intel Pentium ® N4200 Q7/4G DDR3L Rev. B2
EQM-APL-N3350-B2R
Intel Celeron® N3350 Q7/4G DDR3L Rev. B2
EQM-APL-J3455-B2R
Intel Celeron® J3455 Q7/4G DDR3L Rev. B2
REV-Q703-B1-00R
Mini ITX Evaluation Carrier Board for Q7 Rev 2.1
ACC-EQMAPLN-SK-1R
Heatsink for EQM-APL N4200/N3350 w/o Fan,H=24mm, supports -20~70C
ACC-EQMAPLN-SD-1R
Heatspreader for EQM-APL N4200/N3350
