Specification
Download
System Information
Processor
NXP i.MX 7Dual Processor / Dual Arm® Cortex®-A7 Cores And Cortex-M4
System Memory
On-Board 2GB DDR3L
Board
EMX-IMX7
Platform Controller Hub
NXP MCIMX7D7DVM10SD
I/O Chipset
PCA9555
Antenna
2 x Antenna with dust cover
Expansion
Expansion
1 x M.2 E-Key socket for WiFi/BT module expansion
Storage
Other Storage Device
1 x Micro SD card slot
Storage
On-Board 8GB eMMC / microSD Socket
Audio
Speaker Output
2 x 0.5W Speakers
Audio Codec
CIRRUS WM8960 Stereo codec
Ethernet
LAN Chipset
ICPlus IP1001M Gigabit Phy
LAN Port
1 x RJ-45 Supports 10/100/1000 Base-T
Power Requirement
Adapter
Input: 100~240Vac/50~60Hz ; Output: 60W (12V/5A)
DC Input
DC-12V
DC Input Connector
Lockable DC Jack
Software Support
OS
Android5.1 / Linux 4.15, (Yocto 2.1)
Certification
Certification Information
CE (EN 62368-1) FCC Part 15 Class B
In-Box Accessory
Accessory
1 x Power Adapter
1 x US Power cord
1 x Wall mounting bracket
1 x Wall locking bracket
1 x Pan head screws (D6.8, M4*10mm) with washer (D8.1)
4 x Thumb screws (M4*10L)
2 x Pan head screws (D6.85, M4*6mm)
External I/O
Wireless LAN Antenna
Optional with M.2 module
USB
2 x USB 2.0 (Edge I/O) 1 x Micro USB for USB OTG
LAN Port
1 x RJ-45 connector for Gigabit Ethernet
Panel
Touch Interface
USB
Contrast ratio
15:1 (Typ.)
Touch Screen
Built-in Projective Capacitive Touch Screen
Display Type
E Paper Display
Resolution
H:2160 × V:2880
LCD Size
42"
Pixel pitch
0.2975 (H) x 0.2975 (V)
LCD Panel
E Ink ED420TE1
Touch Controller
ILI2325
Viewing angle
180(U), 180(D), 180(L), 180(R)
Touch Light Transmission
≧80%
I/O
Serial
2 x TTL Serial I/F
Supports Optional TTL to RS-232 Converter
Supports Optional TTL to RS-485 Converter Supports Optional TTL to USB Converter
GPIO
4 x GPIO I/F
Mechanical
Color
Black
Reliability
Unit Weight
6.5kg
EMI Test
CE/FCC-B
Packaging Vibration Test
With On-Board 8GB eMMC/On-Board 1GB DDR3L: 0.5 Grms, IEC 60068-2-64, Random, 5~ 500Hz, 1hr/axis (Only for Z-axis)
Operating Humidity
5% ~ 90% relative humidity, non-condensing
Storage Temp.
-20°C ~ 60°C
Packaging Drop Test
Avalue Standard Test Criteria (Change to use ISTA-1A)
Mechanical & Environmental
Weight
6.5Kgs
Operating Humidity
5% ~ 90% relative humidity, non-condensing
Operating Temp.
0°C ~ 40°C standard temp, -15°C~65°C wide temp is optional
VESA
100x100
Dimension (W x L x H)
918.8 x 704.6 x 37.6 mm
Storage Temp.
-20°C ~ 60°C
Mounting Kit
3 steps mounting kits
Ordering Information
Ordering Information
EPD-42T-SIT-A1R 42" E Ink/NXP EMX-IMX7/PCAP/LAN/Android
