Processor

Onboard Intel® Celeron® SoC BGA Processor N3350 (Apollo Lake Platform)- (with CPU Bottom Mounted)

System Memory

1 x 204-Pin DDR3L 1866MTs SO-DIMM up to 8GB

Board

ECM-APL2-B

Platform Controller Hub

Intel® Apollo Lake SoC Processor integrated Gen9 LP graphics

I/O Chipset

EC (IT8528VG)

BIOS

AMI uEFI BIOS, 128Mbit SPI Flash ROM

Hard Driver Bay

1 x SATA III

Expansion

1 x Full size Mini PCIe Supports mSATA
1 x Half size Mini PCIe

Storage

1 x 2.5 Drive Bay
1 x mSATA (Shared from mPCIe)

Speaker Output

2 x 2W speaker(optional, need to add AUX-031 Amplifier Board)

Audio Codec

Realtek ALC888S, supports 5.1-CH

LAN Chipset

1 x Intel® I211AT
1 x Intel® I210IT

Ethernet Interface

10/100/1000 Base-Tx GbE compatible

DC Input

DC-19V

DC Input Connector

Lockable DC Jack

OS

Android 8.1(default) / Windows 10 IoT

Certification Information

CE/FCC Class A

Wireless LAN Antenna

2 x Antenna Mounting with Dust Cover(Optional)

Wireless LAN

mPCIe Wi-Fi/BlueTooth module(Optional)

USB

4 x USB 3.1 (Gen1 5Gbps)

LAN Port

2 x RJ-45

Video Port

1 x HDMI (1.4b): Max. Resolution 3840 x 2160 @ 30Hz

LCD Panel

E Ink ED312TT3

Pixel pitch

0.27

LCD Size

31.2

Resolution

H:2560 × V:1440

Display Type

E Paper Display

Touch Screen

P-cap touch(optional)

Contrast ratio

12 (Typ.)

Touch Interface

USB

Touch Controller

EETI-EXC86H80128SCAG

Viewing angle

180(U), 180(D), 180(L), 180(R)

Video

31.2 E Paper Display (E Ink ED312TT3): H:2560 × V:1440
1 x HDMI (1.4b): Max. Resolution 3840 x 2160 @ 30Hz

Serial

1x DB-9 male connector for COM1 supports RS232/422/485 (selectable by Jumper and BIOS without changing Cable, w/ Auto Flow)

Bluetooth

Optional Bluetooth 5.0

WLAN

Optional dual-band 2.4/5.0GHz wireless LAN

Color

Black

Unit Weight

7kg

EMI Test

CE/FCC Class A

Weight

7Kgs

Vibration Test

With SSD/mSATA : 1.5Grms, IEC 60068-2-64, Random, 5 ~ 500Hz, 30min/axis

Shock Test

With CF/SSD : 10Grms, IEC 60068-2-27, Half Sine, 11ms

Storage Temp.

-20 ~ 60°C (-4 ~ 140°F)

Operating Humidity

0% ~ 90% Relative Humidity, Non-condensing

Operating Temp.

0 ~ 50°C (32 ~ 122°F)

Drop Test

ISTA-2A, IEC-60068-2-32 (96.5cm)

Dimension (W x L x H)

750 x 445 x 36.7 mm

VESA

(400 × 200 mm) VESA mount compliant

Ordering Information

EPD-3133-OFD-A1R (Open Frame) 31.2"E Ink/N3350/4GRAM/64GSSD/2LAN/4USB
EPD-3133-SID-A1R (SID mode) 31.2"E Ink/N3350/PMMA/4GRAM/64GSSD/2LAN
EPD-3133-TFD-A1R (True Flat Glass)31.2"E I nk/N3350/Glass/4GRAM/64GSSD/2LAN
EPD-3133-TFT-A1R (True Flat Touch) 31.2"E Ink/N3350/Pcap/4GRAM/64GSSD/2LAN
RCC-EPD-WIFI-01R ePaper WPET-239ACN(BT) WIFI kit
RCC-EPD-LTE-01R ePaper EG25-G Quectel LTE kit
