Image Sensor

1/2.8" CMOS

Power Frequencies

50 Hz, 60 Hz

Image Processing

Mirror / Flip / Freeze / WDR / BLC

Camera Control - Interfaces

RS-232 / RS-422 / Ethernet

Camera Control - Protocols

VISCA (RS-232 / RS-422 / IP), CGI (IP)

Preset Positions

10 (IR), 256 (RS-232, RS-422, IP)

TV Lines

1000 (Center / Wide)

Preset Speed

Pan: 200° / sec, Tilt: 200° / sec

Pan / Tilt Speed (Manual)

Pan: 0.1° to 100° / sec, Tilt: 0.1° to 100° / sec

Pan / Tilt Angles

Pan: ±170°, Tilt: +90° / -30°

Minimum Working Distance

0.1 m (Wide) , 1.2 m (Tele)

Aperture (Iris)

F = 1.8 (Wide) to 4.7 (Tele)

Focal Length

f = 4.5 mm (Wide) to 90 mm (Tele)

Total Zoom

20X

Digital Zoom

1X

Optical Zoom

20X

White Balance

Auto / Manual

Exposure Control

Auto, Manual, Priority AE (Shutter, IRIS), BLC, WDR

Shutter Speed

1/1s to 1/10,000s

Viewing Angles

DFOV: 69.2° (Wide) to 4.1° (Tele)
HFOV: 62.3° (Wide) to 3.6° (Tele)
VFOV: 37.7° (Wide) to 2.1° (Tele)

Gain

Auto, Manual

S/N Ratio

≥ 50 dB

Minimum Illumination

0.5 lux (50 IRE, F1.6, Max. AGC, 1/30)

Output Resolutions

Resolutions: 4K / 1080p / 720p
Frame Rates: 60 / 59.94 / 50 / 30 / 29.97 / 25

Effective Picture Elements

8 Megapixels

Mode

Eye Tracking

Channel

2ch Stereo

Codec

AAC-LC (48K)

Built-in Microphone

1 (Omni-Directional)

Video Outputs

HDMI, IP, USB

Audio Outputs

HDMI, IP, USB

Power Requirement

12V

PoE

PoE+ ( IEEE802.3at )

Operating Conditions

Temperature: 0°C to +40°C ; Humidity: 20% to 80%

Storage Conditions

Temperature: -20°C to +60°C ; Humidity: 20% to 95%

Dimensions (W x H x D)

180 x 145 x 183.5 mm

Net Weight

1.7 ( ± 0.1 ) kg

Application

Indoor

Security

Kensington Slot

Power Consumption

24W

Housing Material

Anti-UV

IR Night Vision

Yes

IR Remote Control

Yes

Protection Mode

Privacy Mode, Privacy Indicator

Resolution

4K 60fps

Network Video Compress Formats

H.264, H.265, MJPEG

Maximum Frame Rate

4K 60fps

Bit-rate Control Mode

VBR, CBR

Range of Bit-rate Setting

512Kbps to 64Mbps

Network Interface

10 / 100 / 1000 Base-T

Multi-Stream Capability

2 (RTSP / Web page), 4K 60fps Max.

Network Protocols

IPv6, IPv4, TCP, UDP, ARP, ICMP, IGMP, HTTP, DHCP
RTP/RTCP, RTSP, RTMP,VISCA over IP

Connector

USB 3.0 (Type-B)

Video Formats

MJPEG

Maximum Video Resolution

2160p

USB Video Class (UVC)

UVC 1.1

USB Audio Class (UAC)

UAC 1.0

IP Search and Configuration Tool

Support Windows® 7 or later

PTZ Management Aver Viewcare

Support Windows® 7 or later

PTZ Control Panel

Supports iOS & iPadOS® 11 or later

Camera Setting Tool

Supports Windows® 7 or later, macOS® 10.14 or later

Camera

3 Years

Accessories

1 Year

Live Video Preview

Yes

Camera PTZ Control

Pan, Tilt, Zoom, Focus, Preset Control

Camera/Image Adjustment

Exposure, White Balance, Picture

Network Configuration

DHCP, IP Address, Gateway, Subnet Mask, DNS

Package Contents

Camera, Drilling Paper, Ceiling Mount Bracket, Quick Start Guide, Cable Fixing Plate,
M2 x 4 mm Screw (x3), Power Adapter & Power Cord, 1/4”-20 L=6.5 mm Screw (x2),
Remote Control, M3 x 6 mm Screw (x3), USB Cable (Type-B

Optional Accessories

AVer CL01 PTZ Camera Controller, L-Type Wall Mount
