Specification
Download
System Information
Other
1 x DP 1 x Line in 1 x Line out
MCU
RTD2525A
Board
HID-2100 AD board
Audio
Speaker Output
2 x 2W
Power Requirement
DC Input Connector
Lockable DC Jack
DC Input
+24V
Certification
Certification Information
CE, FCC
External I/O
USB Port
2 x USB 2.0
Panel
LCD Size
21.5"
Display Type
Full HD
Resolution
1920 x 1080
Pixel pitch
0.24795 (H) x 0.24795 (V)
Luminance
250 cd/m2
Contrast ratio
1000
Viewing angle
89(U), 89(D), 89(L), 89(R)
Response time
22 ms
Backlight
LED
Touch Type
Projective capacitive multi-touch up to 10 points
Touch Light Transmission
86%
Touch Controller
USB touch (EETI EXC3188)
I/O
HDMI
1 x HDMI
VGA
1 x VGA
Mechanical & Environmental
Operating Temp.
0°C ~ 40°C (32°F ~ 104°F)
Storage Temp.
-10°C ~ 60°C (-14°F ~ 140°F)
Operating Humidity
40°C @ 95% relative humidity, non-condensing
Weight
5.5 kg
Vibration Test
With SSD/mSATA : 1.5Grms, IEC 60068-2-64, random, 5 ~ 500Hz, 30min/axis
Shock Test
With CF/SSD : 10Grms, IEC 60068-2-27, half sine, 11ms
IP Rating
Front IP65
Dimension (W x L x H)
539.6 x 342.6 x 45.2 mm
System Fan
Fanless
Construction - Front
White plastic
Construction - Rear
White plastic
Finishing
Anti-microbial
Fanless
Yes
Color
White
Component
Adapter
+24V
Ordering Information
Ordering Information
HID-2100-252-A1R
HID 21.5 PCAP Multi-touch Monitor
1920x1080/DP/HDMI/VGA/Line in/Line out/DC out 24V 30W/2W speaker
Front OSD key/2xUSB/USB type B for Touch/
24V DC in/120W Medical Power adapter
Power Cord:
E1702031000R EU Power Cord
E1702031833R US Power Cord
E170203183CR JP Power Cord
E170P060380R UK Power Cord
E1702031831R AU Power Cord
E170P060391R CN Power Cord
