SPC-1533
15" Intel® Celeron® Processor N3350 Fanless Stainless Steel Chassis Touch Panel PC with Full IP-65
FEATURE
Intel® Celeron® Processor N3350
Projective capacitive touchscreen full flat design
Side waterproof power button
Rich I/O 2 x USB, 1 x COM (DB9), 1 x LAN
Metal waterproof connectors
Full system IP65, IPX9K
Optional NFC/ WiFi/ auto dimming/ high brightness solution
Specification
Download
System Information
Processor
Intel® Celeron® Processor N3350, 2M Cache, up to 2.40 GHz
Platform Controller Hub
Intel Apollo Lake SoC integrated
System Memory
1 x 204-pin DDR3L 1600MTs SO-DIMM up to 8 GB
I/O Chipset
EC ITE IT8528E
Watchdog Timer
H/W reset, 1sec. ~ 65535sec./1sec.step
H/W Status Monitor
Monitoring system temperature and voltage with auto throttling control
SBC
EBM-APL
CPU Cooler (Type)
Fanless heatsink
Other
1 x WiFi (optional)
Expansion
Expansion
1 x Mini PCIe
Storage
Storage
1 x 2.5 Drive bay
Display
Graphic Chipset
Intel® Valleyview SoC integrated graphics
supports dual display
Spec. & Resolution
HDMI: Max. Resolution 3840x2160 @ 30Hz
LVDS: Max. Resolution 1920x1080 @ 60Hz
eDP: Max. Resolution 4096x2160 @ 60Hz
Audio
Audio Codec
Realtek ALC888S
Audio Interface
Line-out
Speaker Output
2 x 5W
Ethernet
LAN Chipset
2 x Intel® I211AT
Ethernet Interface
10/100/1000 Base-Tx GbE compatible
Power Requirement
DC Input
+12V ~ +26V
ACPI
Single power ATX support S0, S3, S4, S5 and ACPI 3.0 compliant
Software Support
OS
Win10
Certification
Certification Information
CE / FCC Class B
Panel
LCD Size
15", 4:3
Display Type
XGA
Resolution
1024 x 768
Pixel pitch
0.297mm(H) x 0.297mm(V)
Luminance
300 cd/m2
Contrast ratio
2000
Viewing angle
88 (U), 88 (D), 88(L), 88 (R)
Response time
16 ms
Backlight
LED
Touch Type
Projective capacitive multi-touch up to 10 points
Touch Light Transmission
87%
Touch Controller
Onboard USB touch (EETI)
External I/O
USB Port
2 x Waterproof USB 2.0
LAN Port
1 x RJ-45 8-pin (male) for LAN with waterproof cover and chain
COM Port
1 x Waterproof for COM (DB9, RS-232/422/485)
Internal I/O
SATA
1 x SATA III
System Control
LED Indicator
HDD LED, power LED
Mechanical & Environmental
Operating Temp.
0°C ~ 40°C (32°F ~ 104°F)
Storage Temp.
-20°C ~ 60°C (-4°F ~ 140°F)
Operating Humidity
20% ~ 80% Relative humidity, non-condensing
Dimension (W x L x H)
383 x 307 x 52.5mm
Weight
6.42 Kg
Vibration Test
With SSD/mSATA : 1.5Grms, IEC 60068-2-64, random, 5 ~ 500Hz, 30min/axis
Shock Test
With CF/SSD : 10Grms, IEC 60068-2-27, half sine, 11ms
Drop Test
ISTA 2A, IEC-60068-2-32 Test:Ed
IP Rating
Whole system IP65
Mounting Kit
Wall / Stand / VESA 75mm x 75mm, 100mm x 100mm
Power Mode
AT/ATX (ATX is default)
System Fan
Fanless
Construction - Front
Stainless steel
Construction - Rear
Stainless steel
Component
Adapter
Input: 100 ~ 240Vac/ 50 ~ 60Hz
Output: 60W adapter (24V @ 2.5A adapter) AC-DC adapter
Ordering Information
Ordering Information
SPC-1533-335-A3R
intel Celeron N3350 F1-CPU/4GR/32GSSD/LAN/2USB/COM/(DB9)/Speakers/EBM-APL A1.1/Adapter
ACC-ARM-D1R
VESA STAND, 75mm & 100 mm
ACC-ARM-D23R
VESA STAND, 75mm & 100 mm
ACC-SPC-WIFI-1R
Wifi Kits for SPC-15/17/22 802.11b/g/n MPCIe/2Antenna/Cable
E1702031833R
USA Power Cord
E1702031000R
EU Power Cord
E1702031834R
Japan Power Cord
E1702031830R
UK Power Cord
E1702031831R
Australia Power Cord
