Specification
Download
System Information
Processor
Intel® Celeron® J1900 4-Core 2.0GHz processor
Platform Controller Hub
Intel® Valleyview SoC
System Memory
1 x 204-Pin DDR3L 1066/1333MHz SO-DIMMup to 8 GB
I/O Chipset
EC ITE IT8528E
Watchdog Timer
H/W Reset, 1sec. ~ 65535sec. and 1sec./step
H/W Status Monitor
Monitoring CPU & System Temperature and Voltage
SBC
A Version EBM-BYT
B Version EMX-BYT2
Expansion
Expansion
1 x Mini PCIe Supports mSATA
Storage
Storage
1 x CompactFlash Type I/II Socket
1 x 2.5 Drive Bay
Display
Graphic Chipset
Intel® Valleyview SoC integrated Graphics
supports dual display
Spec. & Resolution
HDMI:Max. resolution 1920x1200@ 60Hz
Audio
Audio Codec
Realtek ALC888S
Audio Interface
Line-out
Speaker Output
2 x 2W
Ethernet
LAN Chipset
2 x Intel® I210IT
Ethernet Interface
10/100/1000 Base-Tx GbE compatible
Power Requirement
DC Input
+12V ~ +26V
DC Input Connector
Lockable DC Jack
Software Support
OS
Win 7
Win 8
Linux
Certification
Certification Information
CE / FCC Class B
Panel
LCD Size
17", 4:3
Display Type
SXGA
Resolution
1280x1024
Pixel pitch
0.264mm (H) x 0.264mm (V)
Luminance
350 cd/m2
Contrast ratio
800
Viewing angle
80 (U), 80 (D), 85 (L), 85 (R)
Response time
30 ms
Backlight
LED
Touch Type
5 Wires resistive
Touch Light Transmission
80%
External I/O
USB Port
1 x USB 3.0
3 x USB 2.0
LAN Port
2 x RJ-45
Internal I/O
COM Port
1 x RS-232/422/485
Mechanical & Environmental
Operating Temp.
0°C ~ 40°C (32°F ~ 104°F)
Storage Temp.
-10°C ~ 50°C (14°F ~ 122°F)
Operating Humidity
0% ~ 90% Relative Humidity, Non-condensing
Dimension (W x L x H)
391.5 x 364.5 x 59mm
Weight
5.9 Kg
Vibration Test
With SSD/mSATA : 1.5Grms, IEC 60068-2-64, Random, 5 ~ 500Hz, 30min/axis
Shock Test
With CF/SSD : 10Grms, IEC 60068-2-27, Half Sine, 11ms
Power Mode
AT/ATX (ATX is default setting)
System Fan
Fanless
Construction - Front
White Plastic
Construction - Rear
Gary Plastic
Component
Adapter
Input: 100 ~ 240Vac/ 50 ~ 60Hz
Output: 60W Adapter (12V @ 5A Adapter)
Ordering Information
Ordering Information
PPC-1729-190-A4R
Intel Celeron SoC J1900 2.0GHz/2G DDR3L/32G SSD/2GLAN/COM/SPK/VESA Stand/12~26V input/12V Adapter
PPC-1729-190-B3R
Intel Celeron SoC J1900 2.0GHz/2G DDR3L/32G SSD/2GLAN/COM/SPK/VESA Stand/12V DC input/12V Adapter
