Specification
Download
System Information
Processor
Intel® Pentium® Processor N4200
Platform Controller Hub
Intel® Pentium® SoC integrated Graphics
System Memory
2 x 204-pin DDR3L 1600 & 1333 MHz SO-DIMM supports up to 16GB
I/O Chipset
EC iTE IT8528
Watchdog Timer
H/W reset: 1sec. ~ 65535sec./min. and 1sec. or 1min./step
H/W Status Monitor
Monitoring system temperature and voltage with auto throttling control
Expansion
Expansion
1 x full size mini PCI-e support mSATA
Display
Graphic Chipset
Intel® Pentium® SoC integrated Graphics
Spec. & Resolution
DP++: 4096 x 2160 @ 60Hz (1 x HDMI/DP, 1 x DP++) HDMI/DP: 3840 x 2160 @ 30Hz, 2560 x 1600 @ 30Hz
Audio
Audio Codec
Realtek ALC662 supports 2-CH
Speaker Output
2x 8Ω/2W speaker
Ethernet
LAN Chipset
Intel I211AT Gigabit Ethernet
Ethernet Interface
10/100/1000 Base-Tx GbE compatible
Power Requirement
DC Input
+12V ~ +24V
DC Input Connector
DC Jack
Software Support
OS
Win 10
Certification
Certification Information
CE
FCC Class A
Panel
LCD Size
17.3"
Display Type
Full HD
Resolution
1920 x 1080
Pixel pitch
0.1989×0.1989 mm (H×V)
Luminance
300 cd/m2
Contrast ratio
650
Viewing angle
70/70/60/60
Response time
TR 2/6 ms
Backlight
LED
Touch Type
Projective capacitive multi-touch up to 10 points
Touch Light Transmission
80%
Touch Controller
Onboard USB touch (EETI)
External I/O
USB Port
4 x USB 3.0
LAN Port
1 x RJ-45 Intel® i211AT Gigabit Ethernet
Internal I/O
HDMI
1 x HDMI
Display Port
1 x DP, 1 x DP++
Mechanical & Environmental
Operating Temp.
0°C ~ 35°C (32°F ~ 95°F)
Storage Temp.
-20 ~ 60°C (14°F ~ 122°F)
Operating Humidity
20% ~ 80%
Dimension (W x L x H)
445x281x45mm
Weight
4.7 Kg
Vibration Test
With SSD/mSATA : 1.5Grms, IEC 60068-2-64, random, 5 ~ 500Hz, 30min/axis
Shock Test
With CF/SSD : 10Grms, IEC 60068-2-27, half sine, 11ms
Power Mode
AT/ATX (ATX is default setting)
System Fan
Fanless
Construction - Front
Plastic- white
Construction - Rear
Plastic- white
Component
Adapter
AC/DC adapter 100~240V 50~60Hz, 12V/5A
Ordering Information
Ordering Information
APC-1733-420-A1R 17.3 PCAP Touch/FHD/Intel® N4200 Processor/4GB DDR3L/32GB mSATA/1*LAN/4*USB3.0/2*DP/NFC/Front Camera/Adapter
