CPU Processor

MediaTek Genio 510, ARM 6nm Hexa-core
Processor-2*A78/4*A55.

Memory

LPDDR4, 4GB

Storage

32GB eMMC (16GB eMMC optional)

OS Support

Android 13 or Linux Yocto

Ethernet

10/100/1000M

Size

15.6"

Resolution

1920x 1080

Panel Orientation

Landscape

Brightness

>350 cd/m2 (with touch)

Contrast Ratio

800:1

Touch

Multi-touch (PCAP), up to 10 points

WLAN Connectivity

Wi-Fi 6, 802.11 a/b/g/n/ac/ax+BT 5.2

PoE

PoE 802.3at

Proximity sensor

ALS +Prox.

Dimension

373.5mm *243.1mm *26.2 mm

Mounting

Wall Mount/Glass mount
tabletop

Operating Temp.& Humidity

0~40 degrees, 5% to 85%

Storage Temp.& Humidity

-20~60 degrees, 5% to 90%

Lock Type

Kensington lock

Accessory

Mounting bracket, Metal stand

LED Bar

2 (Left/Right)

Speaker

built-in, 2x 1.5W

Microphones

built-in, 2

Camera

1x 13MP, 4K/15 fps (Optional)

NFC

NFC peer to peer mode (13.56MHz)

USB Port

1x USB Type C (OTG/ADB) ;
1x USB Type A (2.0)

Ethernet

1x RJ45 connector with PoE 802.3at

Button (position)

1. Function Button (Top, flush, button)
2. Rescue Button (Top, recessed button)
3. Reset Button (Back, recessed button)

KNX

KNX bus connection block (Red/Black),
Certified KNX Stack (System B) (Optional)

RS485

X1 (Optional)

CAN FD

NA

DC Jack

1x DC Jack

Power Requirement

1x PoE 802.3at
1x DC-in, 12V/3A
