Processor

Intel® Core™ i7-8665UE Processor (8M Cache, up to 4.40 GHz)
Intel® Core™ i5-8365UE Processor (6M Cache, up to 4.10 GHz)
Intel® Core™ i3-8145UE Processor (4M Cache, up to 3.9GHz)
Intel® Celeron® Processor 4305UE (2M Cache, 2.00 GHz)

System Memory

2x 260-Pin SO-DIMM Socket, Max. Up to 64GB DDR4 2400MHz

BIOS Information

AMI uEFI BIOS, 128Mbit SPI Flash ROM

Watchdog Timer

H/W Reset, 1sec. ~ 65535sec.

H/W Status Monitor

Monitoring System Temperature and Voltage with Auto Throttling Control

SBC

ECM-WHL

M.2

1 x M.2 (Key-B, 2242/3042, PCIe, SATA, USB 3.0, USB 2.0, SIM Slot)
1 x M.2 (Key-E, 2230, PCIe, USB2.0, CNVi)

M.2

1 x M.2 (2242) Key-B
Support RAID 0/1

2.5 Drive Bay

1 x 2.5" Drive Bay (7mm)

Power Button

1 x Power Button

LED Indicator

1 x Storage Access LED

USB

4 x USB 3.1, 2 x USB2.0 (Factory option)

COM Port

1 x RS-232 (Factory Option)

LED Indicator

1 x Power on/off LED
1 x Storage Access LED

LAN Port

2 x RJ-45

Audio

1 x Mic-in, 1 x Line-out

Antenna

2 x Antenna Mounting with Dust Protection Cover

AC/DC Input

1 x Lockable DC Jack

Graphic Chipset

Intel® UHD Graphics 620 (i7-8665UE, i5-8365UE, i3-8145UE)
Intel® UHD Graphics 610 (4305UE)

Resolution

2 x HDMI 1.4: Max. Resolution 4096x2160@24Hz

Audio Codec

Realtek ALC888S

LAN Chipset

1 x Intel® I210AT
1 x Intel® I219LM

Specification

10/100/1000 Base-Tx Gigabit Ethernet Compatible

LED Indicator

1 x Power on/off LED on front side

1 x Storage Access LED on front side

ACPI

Single Power ATX Support S0, S3, S4, S5
ACPI 5.0 Compliant

Power Mode

AT/ATX (ATX is default setting)

Adapter

Input: 100 ~ 240Vdc/ 50 ~ 60Hz
Output: 12V/10A AC-DC 120W Adapter

OS

Win 10, Linux

Certification Information

CE, FCC Class B, UKCA

Operating Temp.

With extended temperature peripherals: -10°C ~ 50°C (14°F ~ 122°F) with 0.5m/s air flow
With extended temperature peripherals: -10°C ~ 40°C (14°F ~ 104°F) with 0.2m/s air flow
With 2.5” hard drive: 0°C ~ 40°C (32°F ~ 113°F) with 0.5m/s air flow

Storage Temp.

-30~70C° (-22°F ~ 158°F)

Operating Humidity

40°C @ 95% Relative Humidity, Non-condensing

Dimension (W x L x H)

177mm x 123mm x 55mm (7” x 4.8” x 2.2")

Weight

2.65lbs(1.2KG)

Vibration Test

With SSD: 5Grms, IEC 60068-2-64, Random, 10 ~ 500Hz, 30min/Axis, 3 Axis

Shock Test

With SSD: 50G, IEC 60068-2-27, Half Sine, 11ms, Z Axis

Drop Test

ISTA 2A, IEC-60068-2-32 Test : Ed, 1 Corner, 3 Edges, 6 Faces

Mounting Kit

Stand (Default)
VESA Mount kit (Factory Option)

Ordering Information

Intel® 8th Gen Core™ i7/i5/i3/Celeron® Processor

EPC-WHL-86-C2-1R (i7-8665UE)
EPC-WHL-83-C2-1R (i5-8365UE)
EPC-WHL-81-C2-1R (i3-8145UE)
EPC-WHL-43-C2-1R (4305UE)
